Product Summary

The EPCS4SI8N is a SRAM-based device that supports active serial configuration, configuration data must be reloaded each time the device powers up, the system reconfigures, or when new configuration data is required. The EPCS4SI8N is a flash memory device with a serial interface that can store configuration data for FPGA devices that supports active serial configuration and reload the data to the device upon power-up or reconfiguration.

Parametrics

EPCS4SI8N absolute maximum ratings: (1)Supply voltage for EPCS1, EPCS4, and EPCS16 With respect to ground: -0.6 to 4.0 V; (2)Supply voltage for EPCS64 and EPCS128 With respect to ground: -0.2 to 4.0 V; (3)DC input voltage for EPCS1, EPCS4, and EPCS16 With respect to ground: -0.6 to 4.0 V; (4)DC input voltage for EPCS64 and EPCS128 With respect to ground: -0.5 to 4.0 V; (5)DC VCC or GND current: 15 mA; (6)DC output current per pin: -25 to 25 mA; (7)Power dissipation: 54 mW; (8)Storage temperature No bias: -65 to 150 ℃; (9)Ambient temperature Under bias: -65 to 135 ℃; (10)Junction temperature Under bias: 135 ℃.

Features

EPCS4SI8N features: (1)1-, 4-, 16-, 64-, and 128-Mbit flash memory devices that serially configure Arria series, Cyclone series, all device families in the StratixR series except the Stratix device family, and FPGAs using the active serial (AS) configuration scheme; (2)Easy-to-use four-pin interface; (3)Low cost, low-pin count, and non-volatile memory; (4)Low current during configuration and near-zero standby mode current; (5)2.7-V to 3.6-V operation; (6)EPCS1 and EPCS4 available in 8-pin small outline integrated circuit (SOIC) package. EPCS16 available in 8-pin or 16-pin SOIC packages. EPCS64 and EPCS128 available in 16-pin SOIC package.
