TEA1733T

SMPS controller IC, 8-SOIC, -0.4 to +30 V, Slope compensation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.38~0.43 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.38~0.43

PartNumber:: TEA1733T

Brand:: NXP Semiconductors - nxp | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tina's store

(Singapore)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-21

From Other Seller

Part Number:TEA1733T
US $0.38 - 0.43
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TEA1733T is a low cost Switched Mode Power Supply (SMPS) controller IC, which is intended for flyback topologies. The TEA1733T operates in fixed frequency mode. To reduce ElectroMagnetic Interference (EMI), frequency jitter has been implemented. For Continuous Conduction Mode (CCM) operation, slope compensation is integrated.

Parametrics

TEA1733T absolute maximum ratings: (1)supply voltage continuous: -0.4 to +30 V; (2)voltage on pin VINSENSE: -0.4 to +5.5 V; (3)voltage on pin PROTECT: -0.4 to +5 V; (4)voltage on pin CTRL: -0.4 to +5 V; (5)input/output voltage on pin OPTIMER: -0.4 to +5 V; (6)voltage on pin ISENSE: -0.4 to +5 V; (7)input current on pin VINSENSE: -1 to +1 mA; (8)input current on pin PROTECT: -1 to +1 mA; (9)current on pin CTRL: -3 0 mA; (10)current on pin ISENSE: -10 to +1 mA; (11)current on pin DRIVER: -0.4 to +1 A; (12)total power dissipation: 0.5 W; (13)storage temperature: -55 to +150 ℃; (14)junction temperature: -40 to +150 ℃.

Features

TEA1733T features: (1)SMPS controller IC enabling low cost applications; (2)Large input voltage range (12 V to 30 V); (3)Very low supply current during start-up and restart (typically 10 mA); (4)Low supply current during normal operation (typically 0.5 mA without load); (5)Overpower or high/low line compensation; (6)Adjustable overpower time-out; (7)Adjustable overpower restart timer; (8)Fixed switching frequency with frequency jitter to reduce EMI; (9)Frequency reduction with fixed minimum peak current at low power operation to maintain high efficiency at low output power levels; (10)Slope compensation for CCM operation.
